IMMERSION ENERGY Air Handling Units: Modular AHU for Full-Scenario Air Treatment
Jul 28, 2026
Project Overview
Industrial and commercial facilities require accurate, stable and sanitary indoor air management. Traditional HVAC equipment cannot easily balance air quality, energy efficiency and long-term reliability. IMMERSION ENERGY provides high-performance modular Air Handling Units for comprehensive air treatment. Equipped with optimized coils and multi-stage filtration, the system adjusts temperature, humidity, airflow and air cleanliness with chilled or hot water. Optional humidification, dehumidification and heat recovery eliminate dust and pollutants, reducing energy use and carbon emissions to achieve stable, energy-saving ventilation.
Product Strengths
IMMERSION ENERGY AHUs adopt ARI-based specifications and comply with Chinese standards, certified ISO9001 and ISO14001. Premium domestic and imported core components ensure steady performance. The proprietary no-cold-bridge design enhances insulation and air tightness, restricting air leakage rate ≤2.5%.
Its double-skin sandwich casing uses 0.5mm galvanized panels and 30mm polystyrene insulation (≥45kg/m³), reinforced by high-performance sealing strips. Dynamically balanced double-inlet centrifugal fans deliver efficient, low-vibration and low-noise operation. High-efficiency heat exchange coils guarantee adequate cooling capacity, with optional breakwater panels limiting condensate carryover below 3×10⁻⁴kg/kg.
Standard modular design enables independent or combined operation, supporting component interchange, easy transport, quick installation and simple maintenance. The rational internal layout reserves access space for cleaning and inspection. Robust construction retains stable appearance long-term. AHUs can work alone or cooperate with fan coil units for fresh air supply, cutting operating costs and improving indoor air quality.
Wide Application
IMMERSION ENERGY AHUs are widely used in machinery, electronics, textile, medical, chemical, energy and food industries. They are also suitable for restaurants, office buildings, hospitals, theatres, supermarkets and gymnasiums to meet high-standard ventilation and air conditioning demands.
Project Significance
Stricter production codes and energy-saving policies make high-grade modular AHUs indispensable infrastructure. IMMERSION ENERGY continuously optimizes AHU structure and performance under strict industrial standards. We deliver economical, energy-efficient and reliable air treatment solutions for global clients, facilitating standardized production, green operation and healthier indoor environments.
For more information about our products and services, please feel free to contact us.
